K2 10 - K&L 2-Post Lift
Two-Post Car Lift - 10,000 Lb. Capacity - Clearfloor
The K&L Supply K2 10 is a heavy-duty clearfloor two-post vehicle lift engineered for professional service shops that need dependable lifting performance, unrestricted under-vehicle access, and flexible installation. Its direct-drive hydraulic system, overhead box-beam construction, and adjustable column configuration make it suitable for a wide range of vehicles, from low-profile cars and EV platforms to full-size trucks.
Engineered through advanced R&D in South Korea, the K2 10 combines structural strength with smooth operation and reduced routine maintenance. K & L lifts are made using SS400 hot-rolled structural carbon steel, with guaranteed minimum tensile strength of 400MPa, the same steel used in high-rise buildings. Self-lubricating components help minimize regular service requirements, while adjustable height and width configurations allow the lift to fit a variety of service-bay layouts.
Key Features
- Clearfloor Design: Keeps the floor between the columns open for easier vehicle positioning and under-vehicle access.
- Direct-Drive Hydraulic System: Provides smooth and consistent lifting performance.
- Korean Precision Engineering: Developed for structural rigidity, dependable performance, and quiet operation.
- High Quality Structural Carbon Steel: Strong, durable and safe.
- Reduced Routine Maintenance: Self-lubricating components help reduce regular greasing and high-wear component service.
- Adjustable Shop Fit: Multiple column width and height configurations accommodate different service-bay layouts.
- Safety Lock: Mechanical Auto-Release / Manual Release Lock.
- EV-Ready Versatility: Designed to support service applications ranging from low-profile performance cars and EV battery platforms to full-size trucks.
Specifications
| Lifting Capacity |
10,000 lbs |
| Lifting Speed |
50-60 seconds |
| Descending Speed |
30-45 seconds |
| Lifting Height |
78-80 in. |
| Long Lifting Arms |
24.60-50.39 in. |
| Short Lifting Arms |
22.00-43.50 in. |
| Clearance Width |
102.36 in. |
| Mechanical Lock Release |
Auto-Release / Manual Release |
| SKU# |
62-66143 |
Caution:
All K2 10 Lifts should only be installed on level concrete floors with a minimum thickness of 6 inches and 4000 psi concrete that has been aged a minimum of 30 days, with rebar anchoring deeply for seismic stability. A qualified person should be consulted to address seismic loads and other local or state requirements.
A constant supply of 230 volt, 1PH, 60Hz, 25 amps electrical is required for this lift. This lift is designed for indoor use only. Outdoor installation is prohibited.
